Description:
A high-performance PLC CPU module from ABB’s AC500 series, tailored for medium to large-scale industrial automation tasks. It integrates powerful processing capabilities, multi-protocol communication, and flexible I/O expansion, supporting complex control logic and real-time data exchange. Compliant with IEC 61131-3 standards, it enables hot-swappable maintenance and seamless integration with ABB I/O modules and third-party devices, ideal for manufacturing, process control, and infrastructure automation.
| Condition |
100% brand new and original |
| Warranty |
One year |
| MOQ |
1PCS |
| Delivery time |
3-5days |
Technical Specifications:
| Parameter Category |
Specific Content |
| Article Number |
3BSE022466R1 (typical) |
| Processor |
32-bit RISC, 400 MHz |
| Memory |
256 MB RAM; 512 MB Flash (expandable) |
| Communication Interfaces |
2x Ethernet (RJ45, 10/100 Mbps), 2x RS485/RS232 |
| Supported Protocols |
PROFINET IO, EtherNet/IP, Modbus TCP, PROFIBUS DP, etc. |
| Power Supply |
24V DC (19.2–28.8V DC) |
| Power Dissipation |
Typ. 8 W, Max. 12 W |
| Operating Temperature |
-25℃ to +60℃ |
| Storage Temperature |
-40℃ to +85℃ |
| Protection Rating |
IP20 |
| Installation |
DIN rail mounting (EN 50022) |
| I/O Expansion |
Compatible with AC500 I/O modules (digital/analog/mixed) |
Similar models:
- PM554-RP
- PM554-RP-AC
- PM554-TP-ETH
- PM564-TP
- PM564-RP
- PM564-RP-AC
- PM564-TP-ETH
- PM564-RP-ETH
- PM564-RP-ETH-AC
- PM556-TP-ETH
- PM566-TP-ETH
FAQ
Q: What systems and I/O modules is the PM554-TP compatible with?
A: As a core module of ABB's AC500 PLC series, it is fully compatible with all AC500 series I/O modules (including digital, analog, and mixed I/O). It also supports integration with third-party automation devices that comply with industrial communication standards via protocols such as PROFINET IO and Modbus TCP.
Q: Can the PM554-TP connect to multiple types of field devices simultaneously?
A: Yes. It is equipped with 2 Ethernet ports and 2 RS485/RS232 serial ports, supporting multiple protocols such as PROFINET IO, EtherNet/IP, and PROFIBUS DP. It can connect to different types of field devices (e.g., sensors, actuators, HMIs) at the same time to realize centralized control and data collection.
Q: What installation requirements does the PM554-TP have?
A: It adopts standard EN 50022 DIN rail mounting, which is consistent with conventional industrial module installation methods. During installation, ensure the ambient temperature is within -25℃ to +60℃, and the cabinet has good ventilation to avoid overheating; the protection level is IP20, so it must be installed inside a closed industrial cabinet to prevent dust and water intrusion.
Q: What should I do if the PM554-TP fails to communicate with the upper computer or field devices?
A: Troubleshoot step by step: 1) Check the physical connection of the communication cable (Ethernet/serial port), and replace the cable if there is damage; 2) Verify that the communication parameters (IP address, baud rate, parity bit, protocol type) of the module and the connected device are consistent; 3) Check the power supply voltage (ensure it is within 19.2–28.8V DC) to avoid communication abnormalities caused by unstable power supply; 4) Use the diagnostic function of Automation Builder software to view communication fault logs for targeted handling.
Q: Can the PM554-TP work normally in low-temperature environments?
A: Yes. Its operating temperature range is -25℃ to +60℃, which can adapt to most low-temperature industrial scenes (such as cold storage auxiliary equipment control, outdoor power distribution cabinets in cold regions). It is recommended to preheat the cabinet before starting up in an environment lower than -20℃ to avoid temporary performance degradation caused by low temperature.
